Housings - HA03-CTC-SL/S-M20 - 10 01 003 0461 - InKonn

https://www.industrial-connector.eu/web/image/product.template/56560/image_1920?unique=d37f44c
InKonn SARE® coupler housing, standard metal version, size A03. Protection rating IP65 / NEMA 4X, 12 – reliable protection against dust and water. Locking: single lever. Housing material: zinc die-cast, colour grey (RAL 7037), finish powder-coated. Temperature range -40…+125°C. CE compliant, RoHS certified. Compatible with all SARE® inserts of the corresponding size.

5.87 € 5.87 EUR 5.87 €

5.87 €

Not Available For Sale

  • IP protection class
  • Number of cable entries
  • Size
  • Locking lever type
  • CE marking
  • China RoHS
  • Housing colour
  • Housing series
  • Thread type/size
  • NEMA protection class
  • Housing surface finish
  • RoHS
  • Max. temperature
  • Min. temperature
  • Lever material
  • Housing material

This combination does not exist.

InKonn

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Chargers
IP protection class IP65
Others
Number of cable entries 1
Size A03
Locking lever type Longitudinal lever
CE marking Yes
China RoHS Compliant
Housing colour Dust grey (RAL 7037)
Housing series Standard
Thread type/size M20
NEMA protection class 4X, 12
Housing surface finish Powder-coated
RoHS Compliant
Max. temperature +125°C
Min. temperature -40°C
Lever material Stainless steel
Housing material Die-cast zinc
