Housings - HA10-HTE-DB-M25 - 10 01 010 1002 - InKonn

https://www.industrial-connector.eu/web/image/product.template/56600/image_1920?unique=34074e8
InKonn SARE® hood housing, standard metal version, size A10. With straight cable entry (M25). Housing height: high profile. Protection rating IP65, IP67 / NEMA 4X, 12 – reliable protection against dust and water. Locking: single lever. Housing material: aluminum die-cast, colour grey (RAL 7037), finish powder-coated. Temperature range -40…+125°C. CE compliant, RoHS certified. Compatible with all SARE® inserts of the corresponding size.

12.42 € 12.42 EUR 12.42 €

12.42 €

Not Available For Sale

  • IP protection class
  • Number of cable entries
  • Size
  • Locking lever type
  • CE marking
  • China RoHS
  • Housing colour
  • Housing height
  • Housing series
  • Thread type/size
  • Cable entry
  • NEMA protection class
  • Housing surface finish
  • RoHS
  • Max. temperature
  • Min. temperature
  • Lever material
  • Seal material
  • Housing material

This combination does not exist.

InKonn

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Chargers
IP protection class IP65, IP67
Others
Number of cable entries 1
Size A10
Locking lever type Longitudinal lever
CE marking Yes
China RoHS Compliant
Housing colour Dust grey (RAL 7037)
Housing height High profile
Housing series Standard
Thread type/size M25
Cable entry Straight cable entry
NEMA protection class 4X, 12
Housing surface finish Powder-coated
RoHS Compliant
Max. temperature +125°C
Min. temperature -40°C
Lever material Die-cast aluminium
Seal material NBR
Housing material Die-cast aluminium
